Yamaha 90116-10563-00 – Bolt, Stud (3XW)

Yamaha 90116-10563-00 – Bolt, Stud (3XW)

Ensure lasting, vibration-resistant fastening with the Yamaha 90116-10563-00 – Bolt, stud (3XW). This OEM Yamaha stud bolt is precision-machined for critical applications where a fixed threaded mount is required. Ideal for securing components that undergo thermal expansion or need frequent servicing, this part supports long-term durability and maintains alignment where it matters most.

Key Features

Genuine Yamaha OEM Stud Bolt – Factory-engineered for exact fit and torque reliability

Dual-End Threading – Provides a secure base for nut-fastened components

High-Strength Construction – Withstands vibration, heat, and mechanical stress

Corrosion-Resistant Finish – Designed to perform in marine and off-road environments

Ideal Use Cases

Commonly used in cylinder heads, intake manifolds, engine casings, and mounting brackets, this stud is essential for areas requiring fixed-position fastening with consistent torque values. It’s especially useful when parts need to be removed and reinstalled without damaging threads in cast components.

Why Stud Bolts Matter in Engine Assemblies

Stud bolts are superior to traditional bolts in applications where alignment, strength, and repeatability are critical. The Yamaha 90116-10563-00 – Bolt, stud (3XW) helps prevent thread wear, ensures consistent gasket seating, and provides a reliable hold in high-stress zones—protecting both performance and serviceability.

Frequently Asked Questions

What does the Yamaha 90116-10563-00 – Bolt, stud (3XW) do?

It acts as a fixed threaded post that allows nuts to secure components like cylinder heads or manifolds, offering better alignment and reusability than standard bolts.

How do I confirm this fits my Yamaha equipment?

Use your Yamaha model and production year to verify compatibility in the official Yamaha parts catalog or check your unit’s service manual.
